9
ADJUSTING HEIGHT
First Step: Before the dishwasher is placed in the cabinetry, the front feet are closed until the end and
the dishwasher is placed in the cabinetry.
Second Step: Adjust the forefoot level with a flat screwdriver to stabilize the dishwasher and raise it
to the enclosure height.
Third Step: Adjust the rear foot level with a Philips screwdriver to balance and raise the dishwasher to
the enclosure height.
- Make sure the dishwasher is plumb and notice dishwasher can be placed with a small clearance
under the counter top.
- For front feet; turning the feet in the direction of the black arrows with the flat screwdriver allows the
dishwasher to move downwards.
- For rear feet; Turning the Philips screwdriver in the direction of the black arrows will take the
dishwasher feet down.
If the height of the enclosure is 33 7/8" to 35 7/8" (860mm-910mm) use short supports as shown in
the figure.
If the height of the enclosure is above 32 9/32" (870mm) use long supports as shown in the figure.
