Weight of 800W AC power
supply unit (EC8005x01-E6)
1.9 lb (0.862 kg)
Weight of 800W DC power
supply unit (EC8005001-E6)
1.76 lb (0.8 kg)
Weight of Fan Tray Kit (includes
3 fan trays) (EC7200BTF-E6) or
EC7200FTB-E6)
1.05 lb (0.47 kg)
Table 2: Environmental specifications
Operating Temperature 0°C to 50°C (32°F to 104°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Operating Humidity 0 to 95 percent noncondensing
Storage Humidity 0 to 95 percent noncondensing
Maximum Operating Altitude 3,048m (10 000 feet) above sea level
Storage Altitude 0 to 12,192m (0 to 40,000ft) above sea level
Acoustic Noise Less than or equal to 35 db at 21°C and less than or equal to 43 db at
50°C. The temperature is allowed to have ±3.5°C deviation around the
threshold of 35C, (measurement methods based on ISO 7779).
Miscellaneous Operating
Considerations
• No heat sources such as hot air vents or direct sunlight near the
switch.
• No sources of severe electromagnetic interference near the switch.
• No excessive dust in the environment.
• An adequate power source is within 6 feet (1.83 meters) of the switch.
One 15-amp circuit is required for each power supply.
• At least 2 inches (5.08 centimeters) of clearance on the front and back
of the switch for ventilation.
• Cables should be dressed to prevent blocking air flow.
Installing a power supply
The VSP 7254XSQ and the VSP 7254XTQ ship with a power supply, but it is not installed in the
chassis. Refer to the following procedures to install either an AC or a DC power supply.
There are two power supply slots (PSU1 on the left side and PSU2 on the right).
• If you only have one power supply, you can install it in either PSU1 or PSU2.
• If you install a second power supply, neither one acts as a primary power supply. The two
power supplies load share equally.
January 2015 Installation Job Aid for Avaya Virtual Services Platform 7200 Series 3
