Chapter 3: Hardware models
Hardware models for VSP 7200 Series
This section lists the VSP 7200 Series hardware.
Two additional VSP 7200 Series models are now available: these are referred to as Port-Licensed
models. By default these models ship with the first twenty-four of the forty-eight 10 Gigabit ports
(SFP+ or RJ45), and the first four of the six 40 Gigabit ports, enabled. The remaining twenty-four 10
Gigabit ports and the remaining two 40 Gigabit ports can be field-enabled through the purchase and
installation of the optional Port License.
VSP 7200 hardware
Table 1: VSP 7200 Hardware
VSP 7200 Series Description Part numbers
VSP 7200 AC models
VSP 7254XSQ – fiber switch
Model EC7200x1B-E6 ships
with back-to-front fan modules
and one back-to-front 460 W
AC PSU.
Model EC7200x1F-E6 ships with
front-to-back
fan modules and
one front-to-back 460 W AC
PSU.
48 1/10 GbE SFP/SFP+ ports
six 40 GbE QSFP+ ports
one 10/100/1000 BASE-T Out-Of-Band
Management Port
one RJ-45 Console Port
one USB 2.0 port
Base Software License
three field-replaceable fan modules
EC7200x1B-E6 and
EC7200x1F-E6
Note:
Replace the “x” with
a country-specific
power cord code.
See the footnote for
details.
VSP 7254XSQ – Port-Licensed
fiber switch
Includes all of the above components, with
the following changes:
24 ports (Slot 1, ports 25 to 48) out of the
48 1/10 GbE SFP/SFP+ ports require a port
license to be operational.
2 ports (Slot 2, ports 5 and 6) out of the six
40 GbE QSFP+ ports require a port license
to be operational.
EC7200x3B-E6 and
EC7200x3F-E6
Note:
Replace the “x” with
a country-specific
power cord code.
See the footnote for
details.
VSP 7254XTQ – copper switch 48 100 Mbps/1 GbE/10 GbE RJ-45 ports
six 40 GbE QSFP+ ports
EC7200x2B-E6 and
EC7200x2F-E6
Table continues…
November 2016 Installing the Avaya VSP 7200 Series 8
