PSA-65C SPECIFICATIONS
FREQUENCY COVERAGE SENSITIVITY
1 MHz to 1250 MHz in one sweep. -95 dBm
200 KHz to 1000 MHz when optional 10 KHz Res B.W. installed.
AMPLITUDE ACCURACY
RESOLUTION BANDWIDTH + 2 dB typical
Automatically selectable by Span Control
FREQUENCY DISPLAY
a) 3 MHz Res B.W. (set span at 125 MHz/Div) 2 x 16 digit backlit LCD
b) 1 MHz Res B.W. (set span at 50 MHz/Div)
c) 300 KHz Res B.W. (set span at 10 MHz/Div) DIMENSIONS
d) 150 KHz Res B.W. (set span at 5 MHz/Div) 11.5"W x 5.5"H x 13.5"D
e) 75 KHz Res B.W. (set span at 1 or .2 MHz/Div)
f) Optional 10 KHz Res B.W. (set span at .2 MHz/Div) WEIGHT
Extends lower frequency range to approximately 200 KHz 18 Lbs / 8.18 Kg
Note: A Narrow Band Cavity Oscillator is swept for .2 MHz/ POWER REQUIREMENTS
Div span so that signals can be observed with low oscillator External 115 VAC 60Hz / 12 VDC
noise contribution. Internal 12V Gel Cell Battery
220/240 Volt models available
REFERENCE LEVELS
+20, 0, -20, -40 dBm / +69, +49, +29, +9 dBmv ACCESSORIES
1.25-2.50 GHz Frequency Extender
INPUT CONNECTOR 2.50-3.75 GHz Frequency Extender
Type BNC (BNC to F adapter included) 950-1450 MHz Frequency Extender
Type N (optional) 3.7-4.2 GHz Frequency Extender
1.7-2.7 GHz Frequency Extender
DISPLAY DCP-20 DC Power Inserter / Block
10 horizontal graticule Divisions (frequency) x 7 vertical AVSAC Carrying Case
graticule Divisions (amplitude). Each vertical Division LPA-1000 Log Periodic Antenna
equals 10 dB or 2 dB. RFP-24 Preamplifier
BNG-1000 Broadband Noise Generator
ADA-10A Analyzer Display Adapter
VDM-2 FM Video Demod/AM Video Conv.
MTG-1000A Microwave Tracking Generator
OSA-20A Oscilloscope Adapter
OPTIONS
10 KHz Resolution Bandwidth
