N T E N T O F U S E
The pneumatic 0727 type tool is designed to place Avdel repetition fasteners (except
1
/
16
” Avlug) making it ideal for batch or flow-
line assembly in a wide variety of applications throughout all industries.
There are two models: the 07271 and 07274 are hand-held and can be suspended vertically through a ring at the rear of the tool.
Both models will place most repetition fasteners, as shown on the tables below.
Both models make use of the same nose equipment. Reference must be made to the Nose Equipment section of the manual when selecting
compatible components for the type and size of fastener used in your application (see pages 11 to 20). Nose jaw dimensions are shown
on page 12 and stated on pages 13 and 14.
CHOBERT
GROVIT
AVLUG
BRIV
FASTENER NAME
07271
3
/ 32"
1
/ 8"
5
/ 32"
3
/ 16"
1
/ 4"
3
/ 32"
1
/ 8"
5
/ 32"
3
/ 16"
1
/ 4"
●●●●●
●●●●
●●
●●●●
●●●●
●●●●
●●
●●●
FASTENER SIZE
07274
RIVSCREW
AVTRONIC
AVSERT
FASTENER NAME
07271
2.5mm
M2.5 M3
2.8mm
3mm 3.5mm 4mm 4-40 6-32
UNC UNC
2.5mm
M2.5 M3
2.8mm
3mm 3.5mm 4mm 4-40 6-32
UNC UNC
●●●
●
●●
●●●
●
●●
FASTENER SIZE
07274
