Tool Specification
Specifications
5
Air Pressure Minimum - Maximum 5-7 bar
Free Air Volume Required @ 5.5 bar 2.1 litres
Stroke Minimum 17 mm
Pull Force @ 5.5 bar 9.34 kN
Cycle Time Approximately 0.9 seconds
Noise Level 75 dB(A)
Weight Including nose equipment 2.1 kg
Vibration Less than 2.5 m/s
2
Dimensions in millimetres
Tool Dimensions
Note: Stem Collector Short
Version Bottle is an accessory
part number 71213-03810.
