AVE GRID - INTRODUCTION; TECHNICAL SPECIFICATIONS

5
•Donotobstructthefanorexhaustgrilletoensureoptimumairpassage.
•Ensureadequateairreturnintotheroomincompliancewithexistingregulationsin
order to ensure proper device operation.
•Iftheenvironmentinwhichtheproductisinstalledalsohousesafuel-operatingdevice
(waterheater,methanestoveetc.,thatisnota“sealedchamber”type),itisessential
to ensure adequate air intake, to ensure good combustion and proper equipment
operation.
•Installtheproductsothattheimpellerisnotaccessiblefromtheairoutletsideas
verifiedbycontactwiththeTestFingerincompliancewiththecurrentsafetyregulations.
•Ceilinginstallation
In order to guarantee the IPX4 degree of protection against moisture in case of ceiling
installation,usetheappropriateceilingmountkit,whichisnotincluded.Useonlythe
rear entry hole for supply cables. If there is a possibility of condensation along the air
dischargeduct,provideadrainagesystemtopreventcondensationfromdischarging
into the environment through the fan.
Attention:donotmounttheproductontheceilingwithoutthiskit.
•Windowinstallation
 Incaseofwindowinstallationitisnecessarytousetheappropriatewindowkit,which
is not included.
Attention:donotmounttheproductonthewindowwithoutthiskit.
INTRODUCTION
GRID(Fig.1)isanaxialfandesignedtoensureairextractioninsmall/medium-sizedrooms
suchasbathrooms,toiletsandkitchens.
Suitableforairdischargedirectlytotheoutsideorinthepresenceofshortlinearduct
(lessthan1.5m).Wall,ceilingorwindowinstallation(Fig.2).
TECHNICAL SPECIFICATIONS
•Material:Highquality,impactandUV-resistantABScolourRAL9010.
•Providedwithinternalautomaticshutterswhichopen/closesmoothlyandquietlyvia
integralthermoactuatorafewsecondsafterthefanison.
•Tightclosingoftheshutterstopreventairowingbackfromoutsidewhenthefanisoff.
•Highefficiencyaerodynamicfanwith“winglet”bladestooptimisequietnessandefficiency.
•Singlephaseinductionmotorwithintergalthermalprotection.
•Motormountedonballbearingsthatguaranteealongerproductlifecycle(30,000h)
andthatmakeitsuitableforcoldclimates.
•Thefanisdoubleinsulated:noearthconnectionisrequired.
•Suitableforcontinuousorintermittentoperation.
•IPX4degreeofprotection.
•Powersupply220-240V~ 50/60Hz.
Code
Airflow
m
3
/h max
Static pressure
Pa max
Power
W max
Sound pressure
dB(A) @3m
VNA90 55 17 11 33
VNA90T 55 17 11 33
VNA100 83 27 11 35
VNA100T 83 27 11 35
VNA100HT 83 27 11 35
VNA120 151 40 16 41
VNA120T 151 40 16 41
VNA120HT 151 40 16 41
VNA150 320 59 26 47
VNA150T 320 59 26 47
VNA150HT 320 59 26 47
