PART2-PART REFERENCE
Ф12'x30"
(3.6m x76 cm)
Ф14'x33"
(4.2m x84 cm)
NO.
NAME QTY SPARE PART QTY SPARE PART
1
Drainage Valve
Cover
1 290366 1 290366
2
Stopper
2 290311 2 290311
3
Drainage Valve
Connector
1 290364 1 290364
4
Hole Strainer (B)
2 290312 2 290312
5 Pool Liner 1 393244 1 393246
Color Blue Blue
1
2
4
5
3
NOTE: Drawing for illustration purpose only. Actual product may vary. Not to scale.
Ф
12' x 30" (
Ф
3.6m x76 cm)/
Ф
14' x 33" (
Ф
4.2m x84 cm)
Model Size Water Capacity Pump Ladder
17794DE/17794EU/17794FR/
17794GB/17794RU
Ф12’ x 30” (Ф3.6m x 76 cm) 1421Gal(5377L)
√ ×
17794
Ф12’ x 30” (Ф3.6m x 76 cm) 1421Gal(5377L)
× ×
17796DE/17796EU/17796FR/
17796GB/17796RU
Ф14' x 33" (Ф4.2m x 84cm) 2286Gal(8652L)
√ ×
17796
Ф14' x 33" (Ф4.2m x 84cm) 2286Gal(8652L)
× ×
