PART2-PART REFERENCE
Ф8'x25" (Ф2.4mx63 cm) Ф10'x30" (Ф3mx76 cm)
NO.
NAME QTY SPARE PART QTY SPARE PART
1
Drainage Valve
Cover
1 290366 1 290366
2
Stopper
2 290311 2 290311
3
Drainage Valve
Connector
1 290364 1 290364
4
Hole Strainer
(B)
2 290312 2 290312
5 Pool Liner 1 393242 1 393243
Color Blue Blue
1
2
4
5
3
Ф8' x 25" (Ф2.4m x63 cm)/Ф10' x 30" (Ф3m x76 cm)
Model Size Water Capacity Pump Ladder
17792DE/17792EU/17792FR/
17792GB
Ф8’ x 25” (Ф2.4mx 63 cm) 548Gal(2074L)
√ ×
17792
Ф8’ x 25” (Ф2.4mx 63 cm) 548Gal(2074L)
× ×
17793DE/17793EU/17793FR/
17793GB
Ф10’ x 30” (Ф3.0m x 76 cm) 956Gal(3618L)
√ ×
17793
Ф10’ x 30” (Ф3.0m x 76 cm) 956Gal(3618L)
× ×
