PREPARATION
PREPARATION
Inside The Box
Check that all these items are included.
Aegis
USB Cable
Quick Guide Info Packet
Parts and Ports
1 Volume Control Knob
2 LED Volume Indicator
3 Kinetic Mute Button
4 LED Mute Indicator
5 High Sensitivity Microphone
6 Micro-USB Port
7 DSP
*
Switch
6 7
3
4
5
2
1
*
Digital Signal Processing
