Avid Technology S6 User Manual

Chapter 3: S6 Automation Module Overview 9
3. Jog Wheel with Mode Switches
The Jog Wheel can be assigned to many functions by enabling one of the Jog Wheel Mode switches. An LED ring surrounding the
Jog Wheel indicates wheel position and other values, depending on the current function of the wheel. The
Shift key at the lower
right of the Mode Switches lets you access the
Shift (secondary) function of any Jog Wheel Mode switch.
The Jog Wheel provides the following switches that determine the function of the wheel (as available on the current DAW).
Jog
Shuttle
Trim
Function / –
Move Selection / +
Scroll Horizontal / Zoom Horizontal
Scroll Vertical / Zoom Vertical
Shift
4. Locate Controls
5. Timecode Display
Above the Locate Controls is the two-row Timecode display.
6. Transport
The following switches are provided in the Transport section:
•
||◄ (RTZ), |◄ (previous), ►| (next), BACK+ ►, RMODE, LOC
• BACK, ◄◄ (REW), ►► (FWD), STOP, PLAY, REC, LOOP
