Press【SETUP】again -> push the joystick down to select the submenu, until “Setup 02/10” shows on
the screen for IP selection-> push the joystick to the right until it shows “IP: Static”-> press【ENTER】;
Use the keyboard to set the IP address of the controller: (Connected with AV-1280 series) 192.168.5.100
-> press【ENTER】to go to the next section;
* Keep the first 3 sections (192.168.5) the same as the connected camera, while the last section different. In this
case, camera: 192.168.5.163; controller: 192.168.5.100.
*If there’re less than 3 digits in the section, push the joystick to the right to go to the next section.
Subnet mask: keep the same as the connected camera. 255.255.255.0-> press【ENTER】to go to the
next section;
Gateway: keep the same as the connected camera. 192.168.5.1-> press【ENTER】
The controller will reboot. You should be able to see “192.168.5.100 ONVIF ” on the screen when the
controller finishes rebooting. It's the controller’s IP information.
d. Set up camera connection
Press【IP】-> enter the IP address of the controlled camera: 192.168.5.163-> press【ENTER】to go to
the next section;
Port (ONVIF): 2000 -> press【ENTER】to go to the next section;
User Name: admin -> press【ENTER】to go to the next section;
Password: admin -> press【ENTER】to go to the next section;
Cam Num: choose any number from 1-255. This Cam Num will be assigned to the current camera.
3 -> press【ENTER】.
You’ll see “Succeed” shown on the screen. Press 【CAM3】, the button will light up, and
“192.168.5.163 ONVIF” will show on the screen. It's the IP information of the controlled camera.
You should be able to control the camera now.
