4 Product Introduction
4.1 LED display:
Input voltage indicator
Time-delay selector
Input switch
Working states indication:
Green LED: Working normal;
Orange LED: Time-delay state;
Red LED light long: Input overvoltage/
under-voltage;
Red LED flash: System protection or fault;
Normal Mode
Buck Mode
Time-delay selector
Boost Mode
4.2 Meter display
Working states indication:
Green LED: Working normal;
Orange LED: Time-delay state;
Red LED light long: Input overvoltage/
under-voltage;
Red LED flash: System protection or fault;
Time-delay selector
Input switch
Input/Output voltage indicator
Working states indication:
Green LED: Working normal;
Orange LED: Time-delay state;
Red LED light long: Input overvoltage/
under-voltage;
Red LED flash: System protection or fault;
Input/Output voltage indicator
Time-delay selector
