AVS Electronics CAPTURE 32 - Security Features; Tamper and Fire Detection

- 38 -
Tamper
The zone dedicated to temper proof (T) and the input zones programmed with the “Tamper” modality, can activate
the alarm relay.
Activates Control Panel Relay: By setting “YES”, the tamper proof alarm will activate the relay in control panel.
Activates Extensions Relay: Setting “N” establishes which relay must not be activated. Setting “S” establishes
which relay must be activated for the tamper proof alarm.
Sirens Activates: Setting “N” establishes which buzzers with serial connection must not be activated. Setting “S”
establishes which buzzers with serial connection must be activated for the tamper alarm.
TAMPER Alarm Memo: By setting “YES”, the tamper proof alarm will activate the Alarm Memorisation Tamper.
TAMPER Reset Memo: By setting “YES”, the tamper proof alarm will activate the Reset Memorisation Tamper.
Activates Buzzer: By setting “YES”, the tamper proof alarm will activate the Buzzer signal in the enabled keypads
Press (CLR) to vary
Press arrows () and () to position the cursor
Press (CLR) to vary (YES / NO)
Press (ENT) to conrm
Tamper
ENT 
Activ CP Relay
YES
Memo Tamp. alarm
YES
Memo Tamp. rest.
NO
Relay on sat.
YYYYYYYY
Activ. buzzer
YES
Fire
Activates Control Panel Relay: By setting “YES”, the re alarm will activate the relay in control panel.
Activates Extensions Relay: Setting “N” establishes which relay must not be activated. Setting “S” establishes
which relay must be activated for the re alarm.
Sirens Activates: Setting “N” establishes which buzzers with serial connection must not be activated. Setting “S”
establishes which buzzers with serial connection must be activated for the re alarm.
Memo Fire Alarm: By setting “YES”, the Alarm Fire proof alarm will activate the Alarm Memorisation.
Memo Fire Reset: By setting “YES”, the Alarm Fire Reset proof alarm will activate the Reset Memorisation.
Activates Buzzer: By setting “YES”, the Alarm Fire proof alarm will activate the Buzzer signal in the enabled keypads.
Detectors Current; It is set by default at (20mA).
The line for re protection detectors with 2-wire connections, functioning at 12V c.c., nds its place in the extension
satellites of XSAT36 and XSATPOWER type.
The alarm happens through recognition of absorption on the line and the threshold can be chosen during programming
of the control panel.
All detectors must be connected in parallel on the same line.
+: 12V c.c. supply output, protected by F2 fuse.
F: ended line, with 4.700 ohm resistance, for re protection detectors with current absorption.
Functioning of the FIRE line; When a detector enters alarm state, it remains that way until it is manually restored.
To bring in quiet the eventual outputs in alarm state, the User Code must be entered, opportunely enabled for reset.
The detector that has caused the alarm remains in alarm state, giving the possibility to check the system.
By pressing key [2] (Res. Fire) the detectors are reset, automatically removing power to the same for 10 sec.
Press (CLR) to vary
Press arrows () and () to position the cursor
Press (CLR) to vary (YES / NO)
Press (ENT) to conrm
ATTENTION: the FIRE input is not certied according to CEI79-2 Standard.
Activ. CP Relay
NO
Relay on sat.
nnnnnnnn
Memo re alarm
NO
Memo re rest.
NO
Activ. buzzer
NO
Fire
ENT 
Detector current
20 (5 .. 35 )
Sirens activ.
YYYYYYYY
Sirens activ.
nnnnnnnn
to following
page
from previus
page
