AVS Electronics CAPTURE 32 - Page 60

- 60 -
Dialler
XGSM485
Server SMTP: This menu is used to set the parameters for sending events via email
SMTP Server: SMTP Server name. Parameter supplied by the service manager.
Socket Port: Technical network parameter
Username: This is the Username required to access the SMTP Server
Password: This is the Password required to access the SMTP Server.
Credit request personalization: In this menu, it is possible to personalize the credit request method, in the
case of variation by the operator. The control panel is programmed for the request by the following operators:
Vodafone > call number = 404 TIM > SMS = PRE CRE SIN \ SMS calling number = 40916
WIND > SMS = SALDO \ SMS calling number = 4155
DO NOT USE THE FOLLOWING ACTION IF THE REQUEST PROCEDURE MATCHES THE ONE ALREADY PROGRAMMED.
Credit telephone number: Introduce the operator phone number to be used by the control panel for calling/
forwarding the SMS
Use SMS Credit: Activating this function, the control panel send the indicated SMS in “Credit SMS” for the credit
request. Placing NO, the control panel will ring only once at the phone number indicated in “Credit phone number”.
Credit SMS: In this menu, it is possible to personalize the credit SMS message, as required by the GMS operator.
SiM B (Secondary SIM Card)
PIN: Enter the valid PIN code of the SIM card.
If the PIN code has been disabled this parameter is ignored.
SIM Credit ctrl: If this function is enabled, the control panel will check the credit of the SIM Card. Should
a rechargeable card be installed, leave “NO”.
GPRS: The parameters for data connection via XGSM are programmed in this menu
APN (Access Point Name): Name of the access point (server) to which a mobile device will try to connect
to gain access to the Internet to make data transfers.
APN: Access point name. If left blank, the panel will use the default names made available by the network
operator used (valid only for Italy): TIM: ibox.tim.it, VODAFONE: web.omnitel.it, WIND: internet.wind
Username: user name for accessing the APN (if required by the operator)
Password: password for accessing the APN (if required by the operator)
Server SMTP: This menu is used to set the parameters for sending events via email
SMTP Server: SMTP Server name. Parameter supplied by the service manager.
Socket Port: Technical network parameter
Username: This is the Username required to access the SMTP Server
Password: This is the Password required to access the SMTP Server.
Credit request personalization: the steps for programming SIM Card B are the same as those described
for SIM Card A.
Press (CLR) to vary
To access other entries press () or ()
Writing keys::
(1)abc1 (2)def2 (3)ghi3 (4)jkl4 (5)mno5 (6)pqr6 (7)stu7 (8)vwx8 (9)yz. (0)_’0
Press arrows () and () to position the cursor
Press (ENT) to conrm
Press (ESC) to go back
SMTP Server
ENT 
SMTP Server
Soket port
0
Username
Password
Credit req. pers.
ENT 
Credit tel. num.
Use SMS Credit
NO
Credit SMS
NO
SIM B
ENT 
SMTP Server
ENT 
SMTP Server
Soket port
0
Username
Password
Credit req. pers.
ENT 
Credit tel. num.
Use SMS Credit
NO
Credit SMS
NO
to following
page
from previus
page
PIN
0000
SIM credit ctrl.
YES
GPRS
ENT 
APN
ENT 
APN
Username
Password
