EWEB / EWEB WIFI
IP Addr
0.0.0.0
Web Port
80
DNS2
0.0.0.0
DHCP
NO
Subnet Mask
0.0.0.0
DNS1
0.0.0.0
Gateway
0.0.0.0
User Password
Socket Port
2101
Inst. Password
DDNS Type
0
DDNS Password
DDNS Username
0
DDNS WebSite
WI FI
ENT 
SSID
The following steps must be congured on the basis of the parameters relating to the network to which
the device is connected:
IP Addr: the IP address that allows access to the XWEB board
Example: To enter the address 192.168.1.5, the numbers must be split as follows
Subnet Mask: Network technical parameter.
Example: To enter the address 255.255.255.0, the numbers must be split as follows
Gateway: Network technical parameter.
Example: To enter the address 192.168.1.1, the numbers must be split as follows
DNS1: Network technical parameter.
Example: To enter the address 192.168.1.1, the numbers must be split as follows
DNS2: Network technical parameter.
Example: To enter the address 192.168.1.10, the numbers must be split as follows
DHCP: NO: DHCP service deactivated
YES: Uses the DHCP service for network parameters
Web Port: Access port through browser; usually congured with a value of 80
HTTPS Port: Secure access port via Browser; 443 is the value that is normally congured.
This parameter can only be used with pre-set peripherals (such as EWEB / EWEB WIFI).
Socket Port: Access port for connection to PC via the proprietary AVS protocol
E.g.: for connection through ELM and XWIN, the value of 2101 is usually congured
Inst. Password: Authentication code for publication of graphic maps
User Password: Master authentication code for registering user access password
DDNS Type: 0 = None; 1 = No IP
The following parameters must be congured only when using a dynamic DNS service:
DDNS Username: Parameter supplied by DDNS service manager
DDNS Password: Parameter supplied by DDNS service manager
DDNS WebSite: Parameter supplied by DDNS service manager
WI FI: In the case of WIFI connection, the following steps must be congured according to the parameters of the
network to which the device will be connected
SSID: the name that allows the users to identify the WIFI network. Technical parameter of the network.
KEY: Network technical parameter.
Crittograa: Network technical parameter.
Firmware update: NOT USED: internal use only.
Press (CLR) to vary
To access other entries press () or ()
Writing keys::
(1)abc1 (2)def2 (3)ghi3 (4)jkl4 (5)mno5 (6)pqr6 (7)stu7 (8)vwx8 (9)yz. (0)_’0
Press arrows () and () to position the cursor
Press (ENT) to conrm
Press (ESC) to go back
