DISARMING
1. Press the
button.
2. The indicators will flash and the siren will chirp three times.
3. The doors will unlock (if optional central locking installed).
4. The LED light on the dash will go out. The system is now disarmed.
ALARM TRIGGER ZONE
1. Disarm the alarm and turn the ignition to ON.
2. Watch the LED light on the dash and count the number of flashes.
It will only flash the first time you turn on the ignition after a trigger.
3. See the table below for zone codes.
If the alarm is triggered while you are away from the vehicle the LED
light on the dash will tell you which zone has been triggered.
Number of flashes Triggered zone
1 Door
2 Bonnet/boot
3 Voltage drop
4 Optional sensor
5 Shock sensor
6 Ignition
