AVS 3010+ - Normal Operation (AVS 3010+;AVS 3010); Arming the System; Alarm Trigger Events; AVS 3010+ Shock Sensor Trigger

ARMING
1. Press the
button.
2. The indicators will flash once and the siren will chirp once.
3. The doors will lock (if optional central locking installed).
4. The LED light on the dash will light solid for 15 seconds.
5. The LED light will then start flashing. The system is now armed.
ALARM TRIGGER
If a door, bonnet or boot is opened while the system is armed the siren
will sound and the indicators will flash for 30 seconds. The system
will then re-set itself.
DOOR AJAR WARNING/ZONE ERROR
If the siren chirps after four seconds on arming a door, bonnet or boot
is open or there is a problem with one of the zones in the vehicle.
The system will exclude that zone until there is no error. See the
table below for the zone error message:
Number of chirps Error zone
1 Door*
2 Bonnet/boot
3 Voltage drop
4 Optional sensor
5 Shock sensor
6 Ignition
* If your vehicle has a factory interior light delay this feature may not be available.
Normal operation AVS 3010+ and AVS 3010
AVS 3010+
The AVS 3010+ can also be triggered from the shock sensor. See
Shock Sensor later in this manual.
