Terminal Block Designation
[For authorized sevice techinician use only]
B. PAWS Control Panel
TB-1 1-Line Hot
2-Line Neutral Incoming Power Supply 120vac, 15 amps, 60 Hz
3-Mech. Ground
TB-2 1-Switched Hot
2-Neutral Wash Solenoid #1, 120vac, 1.5 amps max
3-Switched Hot
4-Neutral Wash Solenoid #2, 120vac, 1.5amps max
5-Switched Hot
6-Neutral Wash Solenoid #3, 120vac, 1.5amps max
TB-3 1-Switched Hot
2-Neutral Wash Solenoid #4 120vac, 1.5amps max
3-Switched Hot
4-Neutral Wash Solenoid #5 120vac, 1.5amps max
5-Switched Hot
6-Neutral Wash Solenoid #6 120vac, 1.5amps max
TB-4 1-Switched Hot
2-Neutral Wash Solenoid #7 120vac, 1.5amps max
3-Switched Hot
4-Neutral Wash Solenoid #8 120vac, 1.5amps max
TB-5 1-Switched Hot
2-Neutral Detergent Pump, 120vac, 1.5apms max
3-Switched Hot
4-Neutral PAWS Alarm Horn, 120vac, 1.5amps max
5-Switched Hot
6-Neutral Fan Contractor, 120vac, 1.5amps max
TB-6 1-Switched Hot
2-Neutral Spare Output [PAW] 120vac 1.5amps max
*3-Switched Hot
*4-Neutral Spare Output [MAF II] 120vac, 1.5amps max
5-Neutral Auxillary
6-Hot Power Tap 120vac, 120amps max
TB-7 *1-NC
*2-C Trouble Dry Contacts [MAF II] 1.5amps @ 28vdc/120vac
*3-NO
*4-NC
*5-C Trouble Dry Contacts [MAF II] 1.5amps @ 28vdc/120vac
*6-NO
TB-8 *1-NC
*2-C Fire Dry Contacts [MAF II] 1.5amps @ 28vdc/120vac
*3-NO
*4-NC
*5-C Fire Dry Contacts [MAF II] 1.5amps @ 28vdc/120vac
*6-NO
TB-9 1-Line Hot PAWS Supervised ]
2-Switched Hot Valve Switch |
3-Line Hot PAWS Manual | 120vac, 25 milliamps
4-Switched Hot Fire Pull Switch |
5-Line Hot PAWS Automatic |
6-Switched Hot Fire Switch ]
TB-10 *1-Line Hot MAF II Water ]
*2-Switched Hot Flow Switch |
*3-Line Hot MAF II Water | 12vdc, 25 milliamps
*4-Switched Hot Pressure Switch |
*5-Line Hot MAF II Supervised |
*6-Switched Hot Valve Switch ]
TB-11 1-Detergent
2-Probe 20vdc, 2 milliamps
*3-Positve
*4-Negative MAF II Horn, 12vdc, 1.5amps
TB-12 1-Positve
2-Negative Battery, 12v, 5A Hours
3-Positve Auxillary
4-Negative Power Tap
*See “Mist-A-Fire Technical Manual” (fig. 10)
