IX. PARTS LIST
A. PAWS PANEL - ELECTRICAL
ITEM NO. AVTEC PART NO. DESCRIPTION
1 112-0301 Fuse Block Bracket
2 EL BLK0306 Terminal Brass Screws
3 EL BLK0307 Terminal Trac
4 EL BLK0308 End Stop for 200-1018
5 EL FUS0304 Fuse [SC-15]
6 EL BLK0315 Fuse Block [Holder]
7 EL SEN0305 Low Level Sensor [Detergent] PC Board
8 EL SWT0318 Flush Toggle Switch
9 EL STA0301 Pull Station [Yellow]
10 EL HRN0301 Sonalert Horn
11 EL ASV0303 PAWS Assembly Model P10 & P20
12 EL TER0301 Output Term for Converting MAF/PAWS Assembly
13 EL RLY0317 Output Relay for Converting MAF/PAWS Assembly
14 PP LBL0302 PAWS Faceplate w/slot Silkscreen/Acrylic
15 PP LBL0303 PAWS Faceplate no slot Silkscreen/Acrylic
16 RP PRB0601 Detergent Probe Cut to Length
B. VCW PANEL - ELECTRICAL
ITEM NO. AVTEC PART NO. DESCRIPTION
1 EL CNT0302 Terminal Block Section
2 EL CNT0348 Terminal Section End Stop
3 EL SWT0348 Push Button w/Black Cap, Start Fan
4 EL SWT0351 Push Button w/Red Cap, Start Wash
5 EL BLK0323 Normally Open Contact Block
[For part no. EL SWT0348 & EL SWT0351]
6 EL SWT0318 Light Switch [20a]
7 EL STA0301 Fire Switch [Pull Station]
8 EL RLY0315 Relay Socket [For part no. EL TMR0312]
9 EL TMR0312 Omnetics Timer Relay]
C. PAWS/VCW PANEL - PLUMBING
ITEM NO. AVTEC PART NO. DESCRIPTION
1 HD TNK0301 5 gal. Detergent Tank
2 HD TNK0302 2 gal. Detergent Tank
3 PB SOL0301 1/2" Water Solenoid
4 PB SOL0302 3/4" Water Solenoid
5 PB SOL0303 1" Water Solenoid
6 PB SOL0304 1-1/4" Water Solenoid
7 PB SOL0305 1-1/2" Water Solenoid
8 PB VLV500 1/2" Ball Valve
9 PB VLV756 3/4" Ball Valve
10 PB VLV750 1" Ball Valve
11 PB VLV790 1-1/4" Ball Valve
12 PB VLV0306 1-1/2" Ball Valve
13 PB VLV0311 1" Supervised Shut-Off Valve [Water]
14 PB VLV0312 1-1/4" Supervised Shut-Off Valve [Water]
