CSD-714 Installation and Operation Manual
1 23-21-01
June 1995
Seattle, WA USA Rev 1 Page 12
Figure 3 - Code Programming
Code Letter
Position J1 Pin
First MP10D MP10C MP10B MP10A
Second MP11D MP11C MP11B MP11A
Third MP13D MP13C MP13B MP13A
Fourth MP15D MP15C MP15B MP15A
Code Letter J1 MP10, MP11, MP13, MP15 Pin Coding
DCBA
A 0001
B 0010
C 0011
D 0100
E 0101
F 0110
G 0111
H 1000
DCBA
J 1001
K 1010
L 1011
M 1100
P 1101
Q 1110
R 1111
S 0000
0 represents a connection to the CODE SEL RETURN, Pin MP9B, or ground.
1 represents no connection to this pin.
Example:
Code FJ-LQ is programmed by jumpering the following pins to pin MP9B:
MP10A & MP10D (Letter F)
MP11B & MP11C (Letter J)
MP13C (Letter L)
MP15A (Letter Q)
