CSD-714 Installation and Operation Manual
1 23-21-01
June 1995
Seattle, WA USA Rev 1 Page 3
SPECIFICATIONS
Model Number: CSD-714
Avtech Part Numbers: 1200008-000 (5 channel, standard self-test)
1200008-001 (2 channel, standard self-test)
1200008-002 (5 channel, auto-reset self-test)
1200008-003 (2 channel, auto-reset self-test)
Certified to TSO: C59
Conforms to RTCA Spec: DO-93 as amended.
RTCA DO-160B Categories: F2BA/MNO/XXXXXXZAAZZZZ
Software Certification: Software has been tested and documented per the requirements
of RTCA paper DO-178A for Level 3 software.
ARINC Characteristics: Complies with the performance, packaging and environmental
requirements of ARINC characteristic 714 and 600.
Number of Channels: Five (-000, -002)
Two (-001, -003)
Size: 1.12" wide, 7.63" high, 12.52" long, defined as 1 MCU by
ARINC 600.
Mounting: Aircraft racking per ARINC Characteristic 600.
Weight: 2.9 pounds
Operating Temperature: -55 degrees centigrade to +70 degrees centigrade continuous.
DO-160B Vibration: Categories MNO for non-vibration isolated mounting in
Helicopters and Fixed Wing turbojet and propeller driven
aircraft.
Operating Altitude: Up to 55,000 feet, non-pressurized.
Input Voltage: 20 to 35 VDC, 27.5 VDC nominal. Voltage below 18 VDC
will inhibit operation of annunciators and decoding.
Input Current: 170 ma nominal, 250 ma maximum
