Avtron K875A - Page 15

Options
Avtron Model K875A Load Bank
TABLE OF CONTENTS (Cont.)
Drawing Option Description
* D37723-4 65 Digital Power Metering Option (DW Style)
** (V, A, F, KW, KVAR, PF, KVA) CT Ratio: 2000:5
* D37723-5 66 Digital Power Metering Option (DW Style)
** (V, A, F, KW, KVAR, PF, KVA) CT Ratio: 4000:5
* D37723-6 67 Digital Power Metering Option (DW Style)
** (V, A, F, KW, KVAR, PF, KVA) CT Ratio: 3000:5
* D37723-7 68 Digital Power Metering Option (DW Style)
** (V, A, F, KW, KVAR, PF, KVA) CT Ratio: 1200:5
* D37723-8 69 Digital Power Metering Option (DW Style)
** (V, A, F, KW, KVAR, PF, KVA) CT Ratio: 1000:5
* D27683-11 70 Control Transformer, 220/110V (for 500 to 2000 kW
Load Banks)
A32404 71 Control Unit, Mounted (Front)
* D38803 72 Dual Voltage Blower/Control Transformer
(2 Stack, 10 HP)
*** A32573-1 73 Gravity Hood Replacement, Single Stack
*** A32573-2 74 Gravity Hood Replacement, Two Stack
*** A32573-3 75 Gravity Hood Replacement, Three Stack
A33333-1 76 Hinged Access Panel, Single Stack
A33333-2 77 Hinged Access Panel, Two Stack
A33333-3 78 Hinged Access Panel, Three Stack
* This drawing includes schematic wiring information.
** This is a supplemental instruction manual on CD.
***Load Banks equipped with Option 73 should be supplied with special Outline Drawing SB3145.
Load Banks equipped with Option 74 should be supplied with special Outline Drawing SB3146.
Load Banks equipped with Option 75 should be supplied with special Outline Drawing SB3147.
