Options Parts List
Avtron Model K875A Load Bank
6-9
Form No. 755A
SCHEMATIC
REFERENCE
DESCRIPTION
AVTRON
P/N
QTY/
UNIT
OPTION #8: OVERVOLTAGE PROTECTION B26013
K101 .RELAY, VOLTAGE CONTROL; INPUT POWER 110 VAC 351653 1
R101 .RESISTOR, CARB COMP 1/2W, 10%, 100 KOHM 110048 1
OPTION #9: ELAPSE TIME METER B26019
M101 .ELAPSED TIME METER: 6 DIGIT, 115/120V, 60 HZ 369222 1
OPTION #10: 1 KW RESOLUTION D27682-1
K10A,11A,12A .RELAY; 3P, N.O., 600 VAC, 9A @ 351889 3
0.05PF, 110 VAC, 60 HZ COIL
XF13-15 .FUSEBLOCK, 30 AMP, 3 POLE, CLASS T 324977 1
F13-15 .FUSE, CARTRIDGE, 10 AMP, 600V, 324480 3
VERY FAST ACTING, CLASS T
R1-9 .LOAD BANK RESISTOR B26020 1
S1-3 .SWITCH, TOGGLE DPST, 4 TERM ON-NONE-OFF 360589 3
OPTION #11: 1 KW RESOLUTION D27682-2
K10,11,12A, .RELAY; 3P, N.O., 600 VAC, 9A @ 351889 6
12B 0.05PF, 110 VAC, 60 HZ COIL
XF13-18 .FUSEBLOCK, 30 AMP, 3 POLE, CLASS T 324977 2
F13-18 .FUSE, CARTRIDGE, 10 AMP, 600V, 324480 6
VERY FAST ACTING, CLASS T
S1-9 .LOAD BANK RESISTOR B26020 1
S1-3 .SWITCH, TOGGLE DPST, 4 TERM ON-NONE-OFF 360589 3
OPTION #12: INTAKE OVERTEMP PROTECTION A25057-1
S4 .TEMP. CONTRLR; K THRMCPLE INPUT 491017 1
RELAY CONT OUTPUT, 120/240V
.THERMOCOUPLE A24741 1
XS4 .SOCKET: 8 PIN, DIN RAIL OR BASE MOUNT 358311 1
OPTION #13: INTAKE OVERTEMP PROTECTION A25057-2
S4 .TEMP. CONTRLR; K THRMCPLE INPUT 491017 2
RELAY CONT OUTPUT, 120/240V
.THERMOCOUPLE A24741 2
XS4 .SOCKET: 8 PIN, DIN RAIL OR BASE MOUNT 358311 2
OPTION #14: INTAKE OVERTEMP PROTECTION A25057-3
S4 .TEMP. CONTRLR; K THRMCPLE INPUT 491017 3
RELAY CONT OUTPUT, 120/240V
.THERMOCOUPLE A24741 3
XS4 .SOCKET: 8 PIN, DIN RAIL OR BASE MOUNT 358311 3
