Avtron K875A - Page 63

Options Parts List
Avtron Model K875A Load Bank
6-18
Form No. 755A
SCHEMATIC
REFERENCE
DESCRIPTION
AVTRON
P/N
QTY/
UNIT
OPTION #47: LOAD SHEDDER D27685-5
K50,51 .RELAY, 3PDT, 120 VAC COIL 351060 2
XK50,51 .RELAY SOCKET DIN RAIL MOUNT 358280 2
XK50,51 .HOLDDOWN SPRING 467550 2
A101 .PRINTED CIRCUIT BOARD ASSY A22829 1
..SCHEMATIC D26034 REF.
DS30 .LAMP, INDICATOR, NEON, PANEL MNT, 329681 1
110/125 VAC, AMBER, .375 MTG. HOLE
S30 .SWITCH, TOGGLE DPDT, 6 TERM, ON-NONE-ON 360591 1
K71 (AUX2) .CONTACT, AUX, SPDT 312361 2
R30 .RESISTOR, 12K OHM, 2W, 5% 119311 1
OPTION #48: LOAD SHEDDER D27685-6
K50,51 .RELAY, 3PDT, 120 VAC COIL 351060 2
XK50,51 .RELAY SOCKET DIN RAIL MOUNT 358280 2
XK50,51 .HOLDDOWN SPRING 467550 2
A101 .PRINTED CIRCUIT BOARD ASSY A22829 1
..SCHEMATIC D26034 REF.
DS30 .LAMP, INDICATOR, NEON, PANEL MNT, 329681 1
110/125 VAC, AMBER, .375 MTG. HOLE
S30 .SWITCH, TOGGLE DPDT, 6 TERM, ON-NONE-ON 360591 1
K71 (AUX2) .CONTACT, AUX, SPDT 312361 2
R30 .RESISTOR, 12K OHM, 2W, 5% 119311 1
OPTION #49: BLOWER DISCONNECT SINGLE STACK A28623-1
.SWITCH, SAFETY, ENCLOSED 361603 1
OPTION #50: BLOWER DISCONNECT MULTIPLE STACK A28623-2
.SWITCH, SAFETY, ENCLOSED 361692 1
OPTION #51: CONTROL TRANSFORMER D27683-9
XF210-212 .FUSEBLOCK 3 POLE 324496 1
F212 .FUSE, CARTRIDGE, 15 AMP, 600V 324346 1
TIME DELAY, CLASS RK-5
F210,211 .FUSE, 20 AMP, 600V, TIME DELAY CLASS RK-5 324143 2
T1 .TRANSFORMER: 1500 VA, 1 PH, 50/60 HZ 371319 1
OPTION #52: CONTROL TRANSFORMER D35895-1
XF210-212 .FUSEBLOCK 3 POLE 324496 1
F212 .FUSE, CARTRIDGE, 9 AMP, 600V, 324431 1
TIME DELAY, CLASS RK-5
F210,211 .FUSE, CARTRIDGE, 8 AMP, 600V, 324699 2
TIME DELAY, CLASS RK-5
T1 .TRANSF, CONT: 850 VA, 240/480 VAC PRI, 371148 1
120 VAC SEC, 50/60 HZ
