Options Parts List
Avtron Model K875A Load Bank
6-20
Form No. 755A
SCHEMATIC
REFERENCE
DESCRIPTION
AVTRON
P/N
QTY/
UNIT
OPTION #59: CONTROL TRANSFORMER D35895-8
XF210-212 .FUSEBLOCK 3 POLE 324496 1
F212 .FUSE, CARTRIDGE, 12 AMP, 600V, 324468 1
TIME DELAY, CLASS RK-5
F210,211 .FUSE, 7 AMP, 600V, TIME DELAY CLASS RK-5 324697 2
T1 .TRANSFORMER, CONTROL 371213 1
OPTION #60: CONTROL TRANSFORMER D35895-9
XF210-212 .FUSEBLOCK 3 POLE 324496 1
F212 .FUSE, CARTRIDGE, 9 AMP, 600V 324431 1
TIME DELAY, CLASS RK-5
F210,211 .FUSE, 6 AMP, 600V, TIME DELAY CLASS RK-5 324393 2
T1 .TRANSF, CONT: 850 VA, 208V PRI, 115 SEC 371247 1
OPTION #61: CONTROL TRANSFORMER D27683-10
XF210-212 .Fuseholder 324496 1
F212 .Fuse, 9 Amp, 600V, Time Delay 324431 1
F210, F211 .Fuse, 4 Amp, 600V, Time Delay 324424 2
T1 .Transformer 371088 1
OPTION #62: DIGITAL METERING UNIT D37723-1
(DW Style), CT Ratio 800:5, RS485
CT1,CT2 .Transformer, Current, 800:5 371200 2
F100-102 .Fuse, 1 Amp, 600V, Time Delay 324449 3
XF100-102 .Fuseblock 324998 1
M1 .Meter, Digital 338344 1
OPTION #63: DIGITAL METERING UNIT D37723-2
(DW Style), CT Ratio 2500:5, RS485
CT1,CT2 .Transformer, Current, 2500:5 370336 2
F100-102 .Fuse, 1 Amp, 600V, Time Delay 324449 3
XF100-102 .Fuseblock 324998 1
M1 .Meter, Digital 338344 1
OPTION #64: DIGITAL METERING UNIT D37723-3
(DW Style), CT Ratio 1500:5, RS485
CT1,CT2 .Transformer, Current, 1500:5 370159 2
F100-102 .Fuse, 1 Amp, 600V, Time Delay 324449 3
XF100-102 .Fuseblock 324998 1
M1 .Meter, Digital 338344 1
OPTION #65: DIGITAL METERING UNIT D37723-4
(DW Style), CT Ratio 2000:5, RS485
CT1,CT2 .Transformer, Current, 2000:5 370157 2
F100-102 .Fuse, 1 Amp, 600V, Time Delay 324449 3
XF100-102 .Fuseblock 324998 1
M1 .Meter, Digital 338344 1
