Avtron K875A - Parts for Panels and Stands (Options 71-79)

Options Parts List
Avtron Model K875A Load Bank
6-22
Form No. 755A
SCHEMATIC
REFERENCE
DESCRIPTION
AVTRON
P/N
QTY/
UNIT
OPTION #72: DUAL VOLTAGE CONTROL D38803
TRANSFORMER & BLOWER CIRCUIT (2 Stack) (Cont.)
K100,130,131, .Relay, 3P, 25A, 600 VAC 350833 10
133-136,
138,139,240
K481 .Relay, Volt Sensing 350583 1
K132,137 .Relay 351925 2
K480 .Relay 351924 1
T2 .Transformer, Control, 50 VA 370528 1
T1 .Transformer 371286 1
S24,S102 .Switch, Toggle 360747 2
S100 .Switch, Pushbutton 361874 1
S101 .Switch, Pushbutton 361873 1
OPTION #76: HINGED ACCESS PANEL, SINGLE STACK A33333-1 1
.Panel, Machining (Top) D32672 1
.Hinge B28406 1
.Latch, Spring, Flush Head 442595 3
.Handle B27422 1
.Label, Warning B15868 1
.Panel, Machining (Bottom) D33312 1
OPTION #77: HINGED ACCESS PANEL, TWO STACK A33333-2 2
.Panel, Machining (Top) D32672 1
.Hinge B28406 1
.Latch, Spring, Flush Head 442595 3
.Handle B27422 1
.Label, Warning B15868 1
.Panel, Machining (Bottom) D33312 1
OPTION #78: HINGED ACCESS PANEL, THREE STACK A33333-3 3
.Panel, Machining (Top) D32672 1
.Hinge B28406 1
.Latch, Spring, Flush Head 442595 3
.Handle B27422 1
.Label, Warning B15868 1
.Panel, Machining (Bottom) D33312 1
OPTION #79: DIGITAL METERING UNIT D37723-9
(DW Style), CT Ratio 5000:5
CT1,CT2 .Transformer, Current, 5000:5 370867 2
F100-102 .Fuse, 1 Amp, 600V, Time Delay 324449 3
XF100-102 .Fuseblock 324998 1
M1 .Meter, Digital 338344 1
