Avtron LPH400 - Replacement Parts List

Replacement Parts List
Avtron Model LPH 400 Resistive Load Bank • Part Number LPH400D43233
6-2
REPLACEMENT PARTS LIST
SCHEMATIC
REFERENCE
DESCRIPTION
AVTRON
P/N
QTY/
UNIT
Form No. 755
AVTRON MODEL LPH LOAD BANK LPH400-
D43233
.SCHEMATIC D43234 REF
.CONTROL PANEL D43237-2 1
DS2 ..LAMP, INDICATOR, AMBER 329681 1
DS1 ..LAMP, INDICATOR, RED 329682 1
M1 ..METER, DIGITAL 338344 1
S100 ..SWITCH, PUSHBUTTON (BLACK) 360309 1
S101 ..SWITCH, PUSHBUTTON (RED) 360308 1
S8,10-17 ..SWITCH, TOGGLE 360589 9
S5 ..SWITCH, PUSHBUTTON (RED) 361873 1
S4 ..SWITCH, PUSHBUTTON (BLACK) 361874 1
S6,7 ..SWITCH, TOGGLE 360747 2
S102 ..SWITCH, TOGGLE 360785 1
S9 ..SWITCH, ROTARY 620288 1
XS9 ..KNOB 453602 1
P2-6 ..CONNECTOR, 10 CONDUCTOR 364874 5
.RESISTOR ASSEMBLY D27552-3 1
K1-3(A & B) ..RELAY B14795 6
K4A,K4B ..RELAY B14796 2
XF1-12 ..FUSEHOLDER 324660 4
F1-F12 ..FUSE, 40A 324419 12
..RESISTANCE ELEMENT, 5 KW A23913-1 6
..RESISTANCE ELEMENT, 10 KW A23913-2 12
..RESISTANCE ELEMENT, 25 KW A23913-4 6
..SPRING, COMPRESSION 473042 48
..PIN, SPRING CLIP 461159 48
..INSULATOR (2.00 LG) 411187 312
..INSULATOR (.50 LG) 411188 48
..INSULATOR 411181 48
..INSULATOR 411182 96
.RESISTOR ASSEMBLY D27553-3 1
K1A,K1B ..RELAY 351885 2
K2A,K2B ..RELAY B14796 2
F7-F12 ..FUSE, 150A 324463 6
F1-F6 ..FUSE, 80A 324420 6
..RESISTANCE ELEMENT, 50 KW A24059 6
..RESISTANCE ELEMENT, 100 KW A23914 6
..SPRING, COMPRESSION 473042 24
..PIN, SPRING CLIP 461156 24
..INSULATOR (2.00 LG) 411187 156
..INSULATOR (.50 LG) 411188 24
..INSULATOR 411146 24
..INSULATOR 411147 48
.RESISTOR ASSEMBLY D27555-3 1
K1A&B,K2A&B ..RELAY 351885 4
F1-F12 ..FUSE, 150A 324463 12
..RESISTANCE ELEMENT, 100 KW A23914 12
..SPRING, COMPRESSION 473042 24
..PIN, SPRING CLIP 461156 24
