Replacement Parts List
Avtron Model LPH 400 Resistive Load Bank • Part Number LPH400D43233
6-3
Form No. 755A
SCHEMATIC
REFERENCE
DESCRIPTION
AVTRON
P/N
QTY/
UNIT
..INSULATOR (2.00 LG) 411187 156
..INSULATOR (.50 LG) 411188 24
..INSULATOR 411146 24
..INSULATOR 411147 48
K100,240 .RELAY B14795 2
K480 .RELAY B16148 1
CT1,2 .TRANSFORMER, CURRENT 371262 2
F100 .FUSE, 10A, 250V 324038 1
XF100 .FUSEBLOCK (2 POLE) 324521 1
F4-9 .FUSE, 600V 324044 6
F101-103 .FUSE, 1A, 600V 324449 3
XF4-9,101-103 .FUSEBLOCK (3 POLE) 324615 3
B1 .MOTOR, 3HP 341147 1
K21,22 .FELAY 350573 2
K30,31 .RELAY 351060 2
K23-29 .RELAY 351650 7
VSR .RELAY 351653 1
XK30,31 .SOCKET, RELAY 358280 2
S51 .SWITCH, DIFF PRESS 360772 1
CB1 .CIRCUIT BREAKER 310446 1
.IMPELLER, FAN 406067 1
XK21,22 .MOUNTING KIT, RELAY 408304 2
XK30,31 .SPRING, HOLD DOWN 467550 2
S50 .SWITCH, TEMPERATURE 362820 1
F440 .FUSE, 0.5A, 250V 324005 1
XF440 .FUSEBLOCK 324964 1
K101 .RELAY, VOLT SENSE 350583 1
T40 .TRANSFORMER, 50VA 370528 1
T4 .TRANSFORMER, 500VA 370984 1
