3.DSP AND DRC INSTALLATION
External dimensions
How to install
WARNING: do not use aggressive cleaning agents or abrasive cloth to clean the display.Simply use
a soft cotton colth lightly damped with water.
4.CONNECTION PANELS-DESCRIPTION
4.1 Input signals
1-2-3-4-5-6-7-8-9-10-11-12
196mm
50mm
307mm
2. OUTPUT; CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 CH9 CH10 CH11 CH12
LIN E INPUT S
MAI N HIGH LE VEL INP UTS
10
9 11
12
SPE AKER OU TPUTS SPE AKER OU TPUTS
CH1 ~CH8 CH9 ~CH12
12
