System components
2 Stopwatch
3 max. Speed
1 Speed
4 Sprint times
Sprint display
Specifies the time depending on the current speed
Indicates the ever reached maximum speed in km/h
Specifies the best Sprint time from 0 to 100 km/h or 0-200 km/h
Specifies currently speed in km/h according to the speedometer
Specifies the maximum reached longitudinal acceleration in g (g = 9,81 m/s
2
)
2
1
3
4
5
5 Longitudinal
acceleration
Graphically represents the longitudinal acceleration, between 0,8G backwards
and 0,8G forwards and is equipped with a drag indicator
(G= 9,81 m/s
2
)
Hold for 2 seconds the provisional maximum of longitudinal acceleration
Specifies the lateral acceleration in G (G= 9,81 m/s
2
)
Specifies the longitudinal acceleration in G (G= 9,81 m/s
2
)
Graphically represents the lateral acceleration between 2,0G to the left and 2,0G
to the right, and is equipped with a towing pointer (G= 9,81 m/s
2
)
Lateral and
Longitudinal
accerlaration
2
1
4
5
3
4 Lateral accelaration
5 Lateral accelaration
1 Longitudinal
acceleration
2 Longitudinal
acceleration bar
3 Peek holder bar
