Article:
E46DGA
Author:
Awron GmbH
Version:
V1.0
Date:
21.11.2015
5Page:
3 Peek holder bar
4 Rpm
6 Oil temperature
2
Graphically represents the boost pressure, between 0 and 1.35 bar, and is
equipped with a towing pointer
Holds the early maximum of loading pressure for 2 seconds
Indicates the charging pressure digital, between 0 and 1.35 bar
1
Indicates the current battery voltage
Specifies the current cooling temperature in °C
Specifies the actual oil temperature between - 40 °C and 150 °C
Rpm SCREEN
3
4
5
6
1 Battery voltage
2 Rpm
5 Cooling water
temperature
System components
3 Peek holder bar
4 Boost pressure
6 Oil temperature
2
Graphically represents the boost pressure, between 0 and 1.35 bar, and is
equipped with a towing pointer
Holds the early maximum of loading pressure for 2 seconds
Indicates the charging pressure digital, between 0 and 1.35 bar
1
Indicates the current battery voltage
Specifies the current cooling temperature in °C
Specifies the actual oil temperature between - 40 °C and 150 °C
Boost pressure
display
3
4
5
6
1 Battery voltage
2 Boost pressure bar
5 Cooling water
temperature
