(L) Timer CH1 & CH2 (R) Timer CH3 & CH4 Continuous
6. Adjusting the intensity
The intensity can be adjusted from 0 – 100. Press or
control to adjust the setting of the respective channels 1-4.
The settings can be adjusted according to the following steps:
1. Turn on the device
After the electrodes are placed firmly
on skin and the lead wires are plugged
in the socket of device, turn the on/o
control.
2. Select mode
Select a mode by pressing the “Mode” control.
The mode you selected will show up on the top of liquid
crystal display. There are 3 modes available: C (Constant), S
(Synchronous) and A (Asynchronous).
When an EMS mode is selected, the LCD display will show
“EMS“. After a mode is selected, press control to enter next
setting. Then press the
or
control to change the settings.
The settings are set as soon as they are selected.
How to set personal EMS parameters
41
STIM-PRO X9+
EN
