4-2 Control Functions
CAUTION:
● Do not operate the electric starter
continuously for more than 5 seconds at
a time or starter damage could occur.
Wait at least 5 seconds between each
start attempt.
● Do not turn the key to the “START”
position with the engine running, or
damage to the electric starter can result.
● See starting instructions prior to starting
the engine. (See pages 6-1 - 6-3 for
details.)
Indicator and Warning Lights
1. Four-wheel locked showing light
2. Fault indicator light of EPS system
3. differential gear lock indicator
4. Coolant temperature warning light
5. Emergency indicator
6. Reverse indicator light “R”
7. Neutral indicator light “N”
8. High-range indicator light “H”
9. Low-range indicator light “L”
10. Seat belt Indicator
11. Mechanical parking brake indicator light “ ”
12. Position indicator
13. Far light indicator
