Control Functions 4-25
1. Spring preload adjusting ring
2. Position indicator
NOTE:
A special wrench can be obtained at a
service center to make this adjustment.
Standard position: B
A-Minimum(soft)
E-Maximum(hard)
1. Special wrench
