AXIS 200+ Users Manual Appendix D: The Auxiliary IO Port
87
This table describes each digital input text string:
Note:
❏ The way in which you use the auxiliary connector is of course, for
you to decide. Axis does not provide any application software, but
instead allows you to determine how this connector is best
utilized. Naturally, we would be more than pleased to learn of any
interesting applications that you might develop.
String Description
input: Input reference
(Input 1= pin 6, Input 2 = pin 7).
current Current port status
(Logical high = 1, Logical low = 0).
last Result of previous read operation.
pulse The number of logical one-to-zero transi-
tions on the I/O pin, since the last read.
time_of_change The time of the last change on the input pin.
