AXIS 200+ Users Manual Appendix E: The RS232 Serial Port
91
Wiring
This is the common wiring schedule for RS232 cables supplied with
most of todays popular modems:
Note:
❏ Some modems are supplied with a cable terminated by 25 pin
DSUB connectors at both ends. Should you have a cable similar
to this, you will need to use a 25 pin Male - 9 pin Female 'gender-
bender' with the pin assignment detailed above. Null modem
cables will not work!
Configuring the
Modem
Before files can be transferred from your AXIS 200+, the host and
remote modems must be configured correctly.
Follow these instructions to configure a US Robotics 28k8+ modem:
1. Connect the modem to your terminal.
2. Check that the modem is responding by issuing the
at command.
Function Pin - server Pin - modem
CD 1 8
-RXD 2 3
-TXD 3 2
DTR 4 20
GND 5 7
NC 6 6
RTS 7 4
CTS 8 5
RI 9 22
