Appendix E: The RS232 Serial Port AXIS 200+ Users Manual
92
3. Continue your configuration in accordance with the session
detailed below (user commands are written in
bold text):
4. To make sure that your modem reloads the established settings on
each occasion it powers up, issue the
ati4 command once the
configuration is complete.
5. To check that the settings have been saved, turn the modem off
and power it on again.
6. Type
ati4. You should not see your own typing at this point,
but if you do, check your modem DIP switches and make sure
that the
ate0 command was issued successfully.
The new settings dump that is displayed should be identical to those
previously saved. If it is, your modem is now ready to be connected to
the AXIS 200+!
Notes:
❏ The described session was performed on a US Robotics modem.
Please be aware that the required settings for other types of
modems may differ from those defined above. Axis are currently
checking the compatibility of the AXIS 200+ with other popular
modem types and will release configuration details for these
shortly.
at
OK
at&f ;load factory default settings
OK
at&b1 ;lock DTE-DCE baud rate
OK
at&h1 ;CTS handshaking on
OK
atm0 ;turn speaker off
OK
ate0 ;command echo off
Note: this inhibits the display
of entered commands.
OK
at&w ;save settings to modem
OK
---------ready ----
