AXIST8134Midspan60W
NO NO
NO
TICE TICE
TICE
•Keepthemidspanawayfromexcessiveheatandhumidityand
freefromvibrationanddust.
•EnsurethatthecablelengthfromEtherhetnetworksourceto
theterminaldoesnotexceed100m(330ft).ThePoEisnota
repeateranddoesnotamplifytheEthernetdatasignal.
•Ifasplitteristobeused,makesureitisconnectedclosetothe
terminalandnotonthemidspan.
•NoON-OFFswitchexists,simplyplugthemidspanintoanAC
powersource.
•EnsurethatallnetworkcablesusedintheinstallationareSTP
andCategory5/5e/6.
•Donotusecountersunkscrewswhenmountingthemidspan.
Screwsize4mm.
Troubleshooting
AXIST8134doesnotpowerup
•Removeandre-applypowertothedeviceandcheckthe
indicatorsduringpowerupsequence.
•Verifythatthevoltageatthepowerinletisbetween
100—240VAC.
•Verifythatthepowerinletcableisfunctional.
Thepowereddevicedoesnotoperate
•VerifythatthepowereddeviceisdesignedforPoEoperation.
•VerifythatastandardCategory5/5e/6,straight-wiredcable
withfourpairsisused.
•VerifythattheinputEthernetcableisconnectedtothe
DATAINport.
•Verifythatthepowereddeviceisconnectedtothe
DATA&POWEROUTport.
