Axis A4010-E User Manual

AXISA4010–EReader
FunctionWire
Color
Notes
Specications
DCinput
+V
Green
Powerinput
fromcontroller
orexternal
powersupply.
Min
12VDC(-10%)
Max
24VDC(+15%)
0VDCREF
0VYel-
low
AWhiteA
RS485
BBrown
Forhalfduplex
RS485(RX/TX)
B
Important
•Therecommendedmaximumcablelengthisupto30m(98.4ft).
ConnectionwithAXISA1001
TousethereaderwithAXISA1001,connecttheRS485wiresfromAtoB
andfromBtoA.
FormoreinformationaboutAxisnetworkdoorcontrollerconnections,see
thehardwarepinchart,generatedthroughthedoorcontroller’shardware
conguration,andtheAXISA1001UserManual,availableatwww.axis.com
10
