AXISA4010–EReader
HardwareOverview
1
Frontplate
2
Coreunit
3
Cable
4
RedLED
5
GreenLED
6
Doublesidedtape
ReaderFeedback
Thetableshowsthefeedbacksignalsthatarepreconguredinthereader
whenconnectedtoanAxisnetworkdoorcontroller.
6
