10
TROUBLE SHOOTING
GENERAL
Power Supply Requirements
Chassis Dimensions
Tone Controls
DC 10-32 Volts, Negative Ground.
178 (W) x 98 (D) x 50 (H)
: ±10 dB
- Bass (at 100 Hz)
- Treble (at 10 kHz)
Maximum Output Power @32V
Current Drain
: ±10 dB
: 4 x 45 watts
: 5 Ampere (max.)
RADIO
Frequency Coverage
IF
Sensitivity
FM
87.5 to 108 MHz
10.7 MHz
4dBμV(S/N=30dB)
AM
522 to 1620 kHz
450 KHz
36dBuV(S/N=20dB)
Stereo Separation >25dB N/A
TROUBLE SHOOTING
Before going through the checklist below, check the wiring connections. If any of the
problems persist after going through this checklist, consult your nearest service dealer.
No power.
The car ignition switch is
not on.
If the power supply is connected to
the car accessory circuit, but the
engine is not running, switch the
ignition key to “ACC”.
The fuse is blown. Replace the fuse.
Volume is at minimum/mute. Adjust volume to a desired level.
Wiring is not properly
connected.
Check wiring connection.
No video output
Function needs to be activated.
Long press the BAND button.
The radio does
not work. The
radio station
automatic
scan does
not work.
The antenna cable is not
Insert the antenna cable firmly.
The signals are too weak. Select a station manually.
The antenna amplifier
has no power.
Connect to 12 volts.
Operation key
doesn't work
The built in MPU is not operating
properlly due to noise.
Press the reset button.
