Axis C1410 Mk II - Buttons; Connectors

AXISC1410MkIINetworkMiniSpeaker
Specifications
Buttons
Controlbutton
Thecontrolbuttonisusedfor:
•Calibratingthespeakertest.Pressandreleasethecontrolbuttonandatesttoneisplayed.
•Resettingtheproducttofactorydefaultsettings.SeeResettofactorydefaultsettingsonpage46.
Microphonedisableswitch
Forlocationofthemicrophonedisableswitch,seeProductoverviewonpage42.
ThemicrophonedisableswitchisusedtomechanicallyturnthemicrophoneONorOFF.Thefactorydefaultsettingforthisswitch
isON.
Connectors
Networkconnector
RJ45EthernetconnectorwithPoweroverEthernet(PoE).
NO NO
NO
TICE TICE
TICE
Thedeviceshallbeconnectedusingashieldednetworkcable(STP).Allcablesconnectingthedevicetothenetworkshallbe
intendedfortheirspecicuse.Makesurethatthenetworkdevicesareinstalledinaccordancewiththemanufacturer’s
instructions.Forinformationaboutregulatoryrequirements,seetheInstallationGuideatwww.axis.com.
43
