Installation
Installation
ThefollowingvideoshowsanexampleofhowyoucaninstallthesensorunitofAXISP1265MkII.
Forcompleteinstructionsonallinstallationscenariosaswellasimportantsafetyinformation,seetheinstallationguideon
axis.com/products/axis-p1265-mk-ii/support.
Towatchthisvideo,gotothewebversionofthisdocument.
help.axis.com/?&piaId=93234&section=install
Connectsensorunits
Whenyouconnectasensorunittoamainunit,werecommendthatyoumaketheconnectionbeforeyoupowerupthemainunit.If
youdisconnectasensorunitandconnectadifferentone,youmustrestartthemainunit.
Shortenthesensorunitcable
Note
Thiscablecanonlybeshortened,notextendedormodiedinanyotherway.
Thesensorunitisdeliveredwithacable.Toshortenthecablefollowthesesteps:
1.Cutthecabletothedesiredlength.Measurefromthesensorunit.
2.Striptheplasticoutercoatingfromtheendofthecable.
3.Peelbacktheshield.
4.Flattenthecoloredwiresintheorderdescribedbelow.
1
Brown
2
White/brown
3
Notused
4
Notused
5
White/blue
6
Blue
NO NO
NO
TICE TICE
TICE
Makesurethatthewiresstayinthecorrectorderandthatthecableshieldmakesgoodcontactwiththeconnectorshield.
5.Insertthewiresallthewayintoashielded6P6CRJ12connector.
6.Useacrimpingtooltofastentheconnectortothecable.
