Seite 64 Netzwerk-Kamera-Serie AXIS P13 Installationsanleitung
Das folgende Anschlussschaltbild zeigt ein Beispiel für den Anschluss eines Zusatzgeräts an die
Netzwerk-Kamera.
1
2
3
4
D
S
G
3,3V
max. 50mA
z.B. Schalter
