AXISQ16NetworkCameraSeries

Conﬁgureyourdevice

1.GotoVideo>Installation>Imagecorrection.

2.TurnonImagestabilization.

Compensateforbarreldistortion

Barreldistortionisaphenomenonwherestraightlinesappearincreasinglybentclosertotheedgesoftheframe.Awideeldofview

oftencreatesbarreldistortioninanimage.Barreldistortioncorrectioncompensatesforthisdistortion.

Note

Barreldistortioncorrectionaffectstheimageresolutionandeldofview.

1.GotoVideo>Installation>Imagecorrection.

2.TurnonBarreldistortioncorrection(BDC).

Monitorlongandnarrowareas

Usecorridorformattobetterutilizethefulleldofviewinalongandnarrowarea,forexampleastaircase,hallway,road,ortunnel.

1.Dependingonyourdevice,turnthecameraorthe3-axislensinthecamera90°or270°.

2.Ifthedevicedoesn’thaveautomaticrotationoftheview,gotoVideo>Installation.

3.Rotatetheview90°or270°.

Verifythepixelresolution

Toverifythatadenedpartoftheimagecontainsenoughpixelsto,forexample,recognizethefaceofaperson,youcanusethe

pixelcounter.
