AXISQ1656-LEBoxCamera
PTZdrivers
PTZdrivers
APTP
Thisisalistofmodelssupportedbythisdriver.ThephysicalinstallationdependsonyourAxisproductandthePTZunit.
Important
CheckwhatserialcommunicationyourAxisproductandthePTZunitwillsupport.
SupportedmodelswithRS4852-wireinterface:
•AXIST99APositioningUnitSeries.
ForinformationaboutcompatibleAxisproducts,seeaxis.com.
OthermodelsmaybesupportedbutthishasnotbeenveriedbyAxis.
Technicalinformation
DEFAULTcapabilitiesforPTZdriver:
DriverAPTP
Version
1.1.0
DEFAULTserialconguration:
PortMode
RS485
BaudRate
115200
DataBits
8
StopBits
1
ParityNone
DEFAULTsupportedcapabilitiesinthisPTZdriver:
Note
DifferentPTZunitsmayhaveothercapabilities(bothlessandmore).
MovementAbsoluteRelative
Continuous
Pan
yesyesyes
Tilt
yesyesyes
Connection
FortheRS485/RS422pinassignmentonyourdevice,seeRS485/RS422connectoronpage65.
Tochangeserialportsettings,gotoSystem>Plaincong>Serialinthedevice’swebinterface.
Pelco
Thisisalistofmodelssupportedbythisdriver.ThephysicalinstallationdependsonyourAxisproductandthePTZunit.
Important
CheckwhatserialcommunicationyourAxisproductandthePTZunitwillsupport.
67
