AXISQ86–ESeries
ChangetheFusesintheBaseUnit
DANGER
Riskofelectricshock.Turnoffpowersupplytoequipmentpriortoworkinginsidebaseunit.
CAUTION
•Theelectricalconnectionsandconduitinstallationsshallbemadebyacertiedelectrician
andincompliancewithlocalregulations.
•Riskofre.Forcontinuedprotectionagainstriskofre,thefusesmustbereplaced
withthesametypeandrating.
1.Separatethepan/tiltunitfromthebaseunitbyremovingthefourscrews,seesection
HardwareOverview.
2.Checkthefusesbyusingamultimeter.Ifthefusesareblown,changethefuses.See
thetablebelow.
VI
DEO
R
S485
GND
B
A
1
2
3
4
REL.2
REL.1
ALARMS
F1
F2
1
Pan/tiltunit
2
Baseunit
3
FuseF1
4
FuseF2
FuseSpecication
VoltageFuseF15x20FuseF25x20
24/100VAC50/60Hz
F6.3A250VT8A250V
23
