AXISQ87BispectralPTZNetworkCameraSeries
Specifications
1
0VDC(-)
2
DCoutput12V,max50mA
A
I/Oconguredasinput
B
I/Oconguredasoutput
Powerconnector
4-pinterminalblockforpowerinput.
24VAC/DCpowerconnector
NO NO
NO
TICE TICE
TICE
Thissectionisvalidforproductspoweredby24VACand24VDConly.
Position
24VAC24VDC
1
ProtectiveearthProtectiveearth
2
24VACPhase
+24V
3
24VACNeutral
0V
4
NotconnectedNotconnected
