Page 6 AXIS T8129 PoE Extender
Technical Specifications
Item
Specifications
Model AXIS T8129 PoE Extender
Data rate 10/100 Mbps half/full duplex
Connectors Shielded RJ-45, EIA 568A and 568B
Network cables Shielded category 5 (or higher)
Display and
indicators
LED indicators are located on the RJ-45 connector
Power indicator: PoE enabled (Green)
Network indicator: Link/activity (Yellow)
Compliance IEEE 802.3af, IEEE 802.3at, RoHS, WEEE, CE
Mounting Wall or shelf
Environment Indoor
Approvals FCC part 15, Class B with FTP cabling, EN 55022 Class B
(Emissions), EN 55024 (Immunity)
Operating
conditions
-10 °C to 50 °C (14 °F to 122 °F)
Humidity max. 85% RH (non-condensing)
Storage -40 °C to 74 °C (-40 °F to 165 °F)
Dimension
(HxWxD)
105 x 40 x 22 mm (4.1” x 1.6” x 0.9”)
Weight 45 g (1.6 oz.)
